Acoustic-Lightboard®

Meets the highest requirements in the sound insulation

Meets the highest requirements in the sound insulation

Acoustic-Lightboard® impresses with high sound absorption and low weight. The combination of a microperforated surface with a close-meshed honeycomb core and the surrounding wood-based frame makes this panel suitable for a wide range of applications. Thanks to customer-specific fabrication, the Acoustic-Lightboard® is always visually and technically adapted to your needs.

Merken

Possible surfaces

Fire protection


Our Acoustic-Lightboard® products meet most high fire protection requirements.

Merken

Merken

Examples

Landtag NRW

Product:  Acoustic-Lightboard®
Americ. Cherry veneer Perforation MR 075250
Year: 2012
Quantity: approx. 140 m2

Landtag NRW

Product:  Acoustic-Lightboard®
Americ. Cherry veneer Perforation MR 075250
Year: 2012
Quantity: approx. 140 m2

Boehringer Ingelheim

Product:  Acoustic-Lightboard®
Steamed Beech veneer Perforation MR 150500
Year: 2008
Quantity: approx. 425 m2

Boehringer Ingelheim

Product:  Acoustic-Lightboard®
Steamed Beech veneer Perforation MR 150500
Year: 2008
Quantity: approx. 425 m2

Boehringer Ingelheim

Product:  Acoustic-Lightboard®
Steamed Beech veneer Perforation MR 150500
Year: 2008
Quantity: approx. 425 m2

German Theatre in Munich

Product:  Acoustic-Lightboard®
Fire retardant construction Perforation MR 100300
Year: 2013
Quantity: approx. 457 m2

German Theatre in Munich

Product:  Acoustic-Lightboard®
Fire retardant construction Perforation MR 100300
Year: 2013
Quantity: approx. 457 m2

Telekom

Product:  Acoustic-Lightboard®
HPL white Perforation MR 100300
Year: 2008
Quantity: approx. 7.200 m2

Telekom

Product:  Acoustic-Lightboard®
HPL white Perforation MR 100300
Year: 2008
Quantity: approx. 7.200 m2

Telekom

Product:  Acoustic-Lightboard®
HPL white Perforation MR 100300
Year: 2008
Quantity: approx. 7.200 m2

More applications

Product:  Acoustic-Lightboard®
Offices, conference rooms, halls an corridors

More applications

Product:  Acoustic-Lightboard®
Offices, conference rooms, halls an corridors

Properties for perfect acoustics

Material structure

With diameters from 1.5 to 0.5 mm (0.06“ to 0.02“), all laminates and veneers can be perforated with the highest precision. The front and rear decks of Acoustic-Lightboard® elements are available with many various perforations.

1. Surface material front side
2. Close-meshed honeycomb structure made of recycled cardboard
3. Wood-based frame (particle board, MDF)
4. Black acoustic fleece
5. Surface material back side
6. Edging (in veneer, ABS, PP, melamine etc. options)

Mounting

Due to its low weight, the Acoustic-Lightboard® offers numerous applications and installation options. In addition to use as furniture components also for quick and easy wall mounting, e.g. using suspension profiles, it can also be installed as a ceiling element in all common T-profile grid systems. In this case, the panel edges can be adapted to the desired joint characteristics.

Acoustics

Micro-perforations with 0.5 to 1.5 mm (0.02“ to 0.06“) diameter in various geometric arrangements allow absorption of the incident sound. With up to 320,000 holes per square meter and its close-meshed honeycomb structure, the Acoustic-Lightboard® ensures pleasant acoustics from office spaces to large halls.

Technical data

Length (max.) 3000 mm (118 1/8“ - depending on selected surface material)
Width (max.) 1250 mm (49 3/16“ - depending on selected surface material)
Thickness (max.) 50 mm (≈2“)
Weight 6.5 – 12.5 kg/m² (1.33 - 2.56 lbs/sqft - depending on selected surface material and dimensions)

Other dimensions and constructions on request.

Surfaces

Our products are available in different finishes.
Different surface materials can be combined with different perforations.

HPL / stained / lacquered

A wide range of HPL laminates, melamine surfaces and color lacquering according to RAL or NCS color codes are available for design.

Wood veneer

Real and natural, that's what makes the charm of wood veneers. In addition to different species of wood, various veneer matching patterns are also available. Please contact us.

Maple
Cherry
Oak
Walnut

Planning documents

Micro-perforations
Text for tenders
Technical data sheets
Handling information

All important information about transport, storage, cleaning and maintenance you can find here as a .PDF download file.



Merken

Brochure

Here you can download our Brochure „Acoustic Systems” as a .pdf file.
